F-13 Aramid braided mesh tube

Retail price
0.0
Market price
0.0
Number of views:
1000
Product serial number
Category
Products
Quantity
-
+
Stock:
0
1
Detail
Size specification
Introduction

Aramid braided mesh tube is made of aramid multifilament, which has strong mechanical toughness, flame retardant, acid and alkali corrosion resistance, and light specific gravity. It can still maintain its good performance under high temperature (above 245), humidity or other harsh environments. It has excellent high temperature resistance and flame retardancy, good dimensional stability, good mechanical properties and soft hand feeling. Widely used in military, aerospace, aviation weapons and equipment for military electronic electromechanical equipment, instrumentation and radio equipment wire harnesses or cables outside the protection from mechanical damage and wiring sheath.
Features
Operating temperature.: -60~240
Standard Colors: Army Green, Black, White
Three proofs, flame retardant, high temperature resistance

Compliant with: RoHS





Technical Data

Product performance Unit Requirement
Oxygen Index (can be customized) % ≥30
flame retardancy - UL94 V0
surface resistance GB/T12703.4-2010 Ω ≥1.0×109
Waterproof (can be customized) GB/T4745.4-2012 - Front Wetted Grade 4 Impervious to Water
Mold resistant GJB150.10A-2009 - Not inferior to class 1
Salt spray resistant GJB150.11A-2009 - No apparent change in appearance
Tensile Strength MPa ≥70% of the initial value
Humid and heat resistant GJB150.9A-2009 - No apparent change in appearance
Tensile Strength MPa ≥70% of the initial value
Radiation resistant QJ10004-2008 - No apparent change in appearance
Tensile Strength MPa ≥70% of the initial value

Dimension
Type Nominal inner diameter
(mm)
max. inner diameter
(mm)
002 2 3
004 4 6
006 6 8
008 8 10
010 10 12
012 12 14
014 14 16
016 16 18
018 18 20
020 20 22
022 22 24
024 24 26
026 26 28
028 28 30
030 30 32
032 32 34
034 34 36
036 36 38
038 38 40
040 40 42
042 42 44
044 44 46
046 46 48
048 48 50
050 50 52
060 60 62
Note
1The above is the size of ordinary nylon braided mesh tube
2The inner diameter refers to the circular diameter of the network pipe, and the folded diameter refers to the flat width of the network pipe.
3The network pipe is flexible and has a large inner diameter/folding diameter tolerance
4Products can be customized according to customer requirements
5For detailed product parameters, please refer to the product specification approval document.


Product diagram
