T1 Composite insulation heat shrinkable tape
Retail price
0.0
元
Market price
0.0
元
Number of views:
1000
Product serial number
Category
Other heat shrink products
Quantity
-
+
Stock:
0
1
Detail
Size specification
| Introduction | |||
| Cross-linked polyolefin material, double-layer composite structure, with hot melt adhesive layer. It is suitable for emergency repair of electric power system, and it is used for insulating and protecting live objects that are irregular in shape and cannot be applied with heat-shrinkable tube or sleeve-shaped insulating materials. | |||
| Features | |||
| Operating temperature：-40℃~105℃ | |||
| Minimum full shrinkage temperature：125℃ | |||
| Voltage level: 36kV and below | |||
| Color: black, red, yellow, green | |||
| Shrink ratio：≥30% | |||
| Insulation, sealing, convenient construction |
| Technical Data | |||
| Property | Test Method | Value | |
| Tensile strength | ASTM D2671 | ≥10.4 MPa | |
| Breakdown elongation | ASTM D2671 | ≥200% | |
| Aging(120℃/168h) Tensile strength Breakdown elongation |
ASTM D2671 |
≥10.4 MPa ≥200% |
|
| Axial change rate | ASTM D2671 | ±10% | |
| Breakdown strength | IEC 60243 | ≥10 kV/mm | |
| Volume resistivity | IEC 60093 | ≥1.0×1014 Ω·cm | |
| Dimension | |||
| Size | Width(mm) | thickness(mm) | Standard length(m) |
| T1-25A | 25.0±2.0 | 0.8±0.2 | 5，10 |
| T1-50A | 50.0±4.0 | 0.8±0.2 | 5，10 |
| T1-100A | 100.0±4.0 | 0.8±0.2 | 5，10 |
| T1-25B | 25.0±4.0 | 1.0±0.2 | 5，10 |
| T1-50B | 50.0±4.0 | 1.0±0.2 | 5，10 |
| T1-100B | 100.0±4.0 | 1.0±0.2 | 5，10 |
Keyword:
T1 Composite insulation heat shrinkable tape
