F-PA Nylon braided mesh tube
Retail price
0.0
元
Market price
0.0
元
Number of views:
1000
Product serial number
Category
Products
Quantity
-
+
Stock:
0
1
Detail
Size specification
Introduction | ||||||||||||||||||||||||||||||||||||||||||||
The nylon braided sleeve is woven from nylon fibers. Soft, lightweight and environmentally friendly. In the multi-branch cable assembly, the end of the nylon braided sleeve is also easy to handle. Suture and bundling can be used to ensure that the bifurcation is soft and easy to bend, and it has a good protection effect on the wire harness in the cavity with narrow space. Special products with flame retardant or anti-static function are available. Resistant to salt spray, 48h without wrinkling and corrosion. It is suitable for the external protection of wire harnesses or cables of military electronic electromechanical equipment, instruments and radio equipment for aerospace and aviation weapons and equipment from mechanical damage and wiring sheath. |
||||||||||||||||||||||||||||||||||||||||||||
Features | ||||||||||||||||||||||||||||||||||||||||||||
Operating temperature.: -55℃~125℃(or customized 150ºC) | ||||||||||||||||||||||||||||||||||||||||||||
Standard colors: army green, grass green, black, red, white, gray | ||||||||||||||||||||||||||||||||||||||||||||
Divided into ordinary, flame retardant, antistatic and other types of products | ||||||||||||||||||||||||||||||||||||||||||||
Compliant with: RoHS
|
||||||||||||||||||||||||||||||||||||||||||||
Technical Data
|
Dimension |
|||
Type | Nominal inner diameter (mm) |
max. inner diameter (mm) |
|
002 | 2 | 3 | |
004 | 4 | 6 | |
006 | 6 | 8 | |
008 | 8 | 10 | |
010 | 10 | 12 | |
012 | 12 | 14 | |
014 | 14 | 16 | |
016 | 16 | 18 | |
018 | 18 | 20 | |
020 | 20 | 22 | |
022 | 22 | 24 | |
024 | 24 | 26 | |
026 | 26 | 28 | |
028 | 28 | 30 | |
030 | 30 | 32 | |
032 | 32 | 34 | |
034 | 34 | 36 | |
036 | 36 | 38 | |
038 | 38 | 40 | |
040 | 40 | 42 | |
042 | 42 | 44 | |
044 | 44 | 46 | |
046 | 46 | 48 | |
048 | 48 | 50 | |
050 | 50 | 52 | |
060 | 60 | 62 | |
Note: | |||
1、The above is the size of ordinary nylon braided mesh tube | |||
2、The inner diameter refers to the circular diameter of the network pipe, and the folded diameter refers to the flat width of the network pipe. | |||
3、The network pipe is flexible and has a large inner diameter/folding diameter tolerance | |||
4、Products can be customized according to customer requirements | |||
5、For detailed product parameters, please refer to the product specification approval document. | |||
Product diagram |
