A2-T2 Semi-hard internal tooth heat shrinkable tube
Retail price
0.0
元
Market price
0.0
元
Number of views:
1000
Product serial number
Quantity
-
+
Stock:
0
1
Detail
Size specification
| Introduction | ||||
| Semi-rigid cross-linked polyolefin heat-shrinkable tube, the inner wall of the radial direction, with zigzag-like unevenness, plays the role of air diversion. Special material design, used in nylon automotive pipes, good anti-sticking effect when processing heat (with mold). | ||||
| Features | ||||
| Operating temperature: -40~150 ℃ | ||||
| Minimum full shrinkage temperature: 135 ℃ | ||||
| Shrink ratio: 1.5:1 ~ 3:1 | ||||
| Halogen-free environmental protection,accondance RoHS、ELV | ||||
| Color: black |
| Technical Data | ||||
| Property | Test Method | Value | ||
| Density | ASTM D2671 | 1.05~1.15g/cm3 | ||
| Tensile strength | ASTM D2671 | ≥14MPa | ||
| Breakdown elongation | ASTM D2671 | ≥350% | ||
| After aging (158℃/168h) Tensile strength Breakdown elongation |
ASTM D2671 | ≥10MPa ≥250% |
||
| Water absorption (23℃/24h) | ASTM D570 | ≤0.5% | ||
| Low temperature flexibility(-40℃/4h) | ASTM D2671 | No cracks | ||
| Heat shock(225℃/4h) | ASTM D2671 | No drips, no flow, no cracks | ||
| Abrasion resistance | TL52668 Type C | ≥144,000 times | ||
| Hardness (Shore D) | ASTM D2671 | 50-60D | ||
| Dimension | ||||
| Size | As supplied(mm) | After shrink (mm) | ||
| A2-T2 | Diameter(Min.) | WT(reference) | Diameter(Max.) | WT |
| 8/5 | 8.0 | 0.40 | 5.0 | 0.60 |
| 10/6 | 10.0 | 0.50 | 6.0 | 0.70 |
| 13/8 | 13.0 | 0.55 | 8.0 | 0.80 |
| 14/10 | 14.0 | 0.70 | 10.0 | 1.10 |
| 18/13 | 18.0 | 1.00 | 14.0 | 1.20 |
Keyword:
A2-T2 Semi-hard internal tooth heat shrinkable tube
