S4 6:1 heat shrinkable tube
Retail price
0.0
元
Market price
0.0
元
Number of views:
1000
Product serial number
Quantity
-
+
Stock:
0
1
Detail
Size specification
| Introduction | |||
| Cross-linked polyolefin material, single-wall or double-wall tape is optional. It is suitable for heat-shrink covering protection and fixed connection in application scenarios with great difference in size, such as cable middle connection and terminal connection, irregular shape cable joints and electrical components, etc. | |||
| Features | |||
| Operating temperature: -55~105℃ | |||
| Minimum full shrinkage temperature: 125 ℃ | |||
| Single wall or double wall with glue optional | |||
| Halogen-free environmental protection | |||
| Shrink ratio：6:1 | |||
| Colour: Black |
| Technical Data | ||||
| Property | Test Method | Value | ||
| Tensile Strength | ASTM D2671 | ≥ 14 MPa | ||
| Breakdown elongation | ASTM D2671 | ≥ 400% | ||
| Aging(136℃/168hrs) Tensile Strength Breakdown elongation |
ASTM D2671 | ≥ 12 MPa ≥ 350% |
||
| Water absorption(23℃/24hrs) | ASTM D570 | ≤ 0.3% | ||
| Low temperature flexibility(-55℃/4h) | ASTM D2671 | No cracks | ||
| Heat shock(200℃/4hrs) | ASTM D2671 | No drips, no flow, no cracks | ||
| Dielectric strength | ASTM D2671 | ≥ 15 kV/mm | ||
| Volume resistivity | ASTM D2671 | ≥ 1.0×1014 Ω·cm | ||
| Dimension | ||||
| Size | As supplied(mm) | After shrink(mm) | Supplied length | |
| S4 | Diameter(Min.) | Diameter(with glue/Max.) | W T(no glue/nomal) | m/pc |
| 19/3.5 | 19 | 3.2 | 3.3 | ≤1.22 |
| 33/5.5 | 33 | 5.5 | 3.8 | ≤1.22 |
| 45/7.5 | 45 | 7.5 | 4.2 | ≤1.22 |
| 55/9.5 | 55 | 9.2 | 4.7 | ≤1.22 |
| 66/11 | 66 | 11.0 | 5.0 | ≤1.22 |
| 75/13 | 76 | 12.7 | 5.0 | ≤1.22 |
| 85/15 | 87 | 14.5 | 5.2 | ≤1.22 |
| 115/20 | 115 | 19.2 | 5.4 | ≤1.22 |
| 160/28 | 160 | 26.6 | 5.8 | ≤1.22 |
| 175/30 | 178 | 29.6 | 6.0 | ≤1.22 |
| 235/40 | 235 | 40.0 | 6.5 | ≤1.22 |
