S2(n) Halogen-free thin wall flame-retardant heat shrinkable tube

Retail price
0.0
Market price
0.0
Number of views:
1000
Product serial number
Quantity
-
+
Stock:
0
1
Detail
Size specification
Introduction
A thin wall, soft, low-smoke, halogen-free, flame-retardant polyolefin heat-shrinkable tube, suitable for insulation protection of wires, wiring harnesses, electronic components, part number identification, mechanical protection, binding and fixing, etc.



Features
Operating temperature: -40~125
Minimum full shrinkage temperature: 125
Shrink rato: 2:1 & 3:1
RoHS compliant
Low-smoke, halogen-free, environmentally friendly, flame-retardant, soft
Color: See the color code below for details



Technical Data
Property Test Method Value
Tensile strength ASTM  D2671 ≥10.4MPa
Breakdown elongation ASTM  D2671 ≥200%
Aging(158/168h)
Tensile strength
Breakdown elongation
ASTM  D2671
≥7.3MPa
≥100%
Water absorption (23/24h) ASTM  D570 ≤0.5%
Low temperature flexibility(-40/4h) ASTM  D2671 No cracks
Heat shock(225/4h) ASTM  D2671 No drips, no flow, no cracks
Breakdown voltage ASTM  D2671 ≥ AC 2500V
Power frequency withstand voltage AC2500V1 minute No breakdown
Volume resistivity ASTM  D2671 ≥1.0×1014Ω·cm
Flame retardancy (except for transparent) UL224 All Tubing
Copper corrosion(158/16h) ASTM  D2671 No corrosion



Dimension
Size As supplied(mm) After shrink (mm) Standard length
S2(n) Diameter Diameter(Max.) W T m
Shrink rato 2:1
0.6  0.9±0.2 0.4  0.28±0.10 200
0.8  1.1±0.2 0.5  0.28±0.10 200
1.0  1.6±0.3 0.65  0.35±0.10 200
1.5  2.1±0.3 0.85  0.35±0.10 200
2.0  2.6±0.4 1.0  0.40±0.10 200
2.5  3.1±0.4 1.3  0.40±0.10 200
3.0  3.6±0.4 1.5  0.45±0.10 200
3.5  4.1±0.4 1.8  0.45±0.12 200
4.0  4.6±0.4 2.0  0.48±0.12 200
4.5  5.1±0.5 2.3  0.50±0.12 100
5.0  5.6±0.5 2.5  0.52±0.12 100
5.5  6.1±0.5 2.8  0.52±0.12 100
6 6.8±0.5 3.0  0.55±0.12 100
7 7.8±0.5 3.5  0.55±0.12 100
8 8.8±0.5 4.0  0.60±0.12 100
9 9.8±0.5 4.5  0.60±0.12 100
10 10.8±0.5 5.0  0.60±0.12 100
11 11.8±0.5 5.5  0.60±0.12 100
12 12.8±0.5 6.0  0.60±0.12 100
13 13.8±0.5 6.5  0.70±0.12 100
14 14.9±0.5 7.0  0.70±0.12 100
15 16.0±0.5 7.5  0.70±0.12 100
16 17.0±0.5 8.0  0.75±0.15 100
17 18.2±0.7 8.5  0.75±0.15 100
18 20.0±0.8 9.0  0.75±0.15 100
20 22.0±1.0 10.0  0.85±0.15 100
22 23.5±1.0 11.0  0.85±0.15 100
25 26.5±1.0 12.5  0.95±0.18 50
28 29.0±1.0 14.0  0.95±0.18 50
30 32.0±1.5 15.0  1.00±0.20 50
35 37.0±1.5 17.5  1.00±0.20 50
40 42.0±2.0 20.0  1.05±0.20 50
45 47.0±2.0 22.5  1.05±0.20 25
50 ≥50 25  1.05±0.20 25
60 ≥60 30  1.10±0.20 25
70 ≥70 35  1.20±0.20 25
80 ≥80 40  1.30±0.20 25
90 ≥90 45  1.30±0.20 25
100 ≥100 50  1.30±0.30 25
120 ≥120 60  1.40±0.30 25
150 ≥150 75  1.40±0.30 25
180 ≥180 90  1.60±0.30 25
Shrink ratio 3:1
1.5/0.5 2.2±0.4 0.5  0.45±0.12 200
3/1 3.8±0.4 1.0  0.55±0.12 200
4.5/1.5 5.2±0.5 1.5  0.60±0.12 100
6/2 6.6±0.5 2.0  0.65±0.12 100
9/3 9.7±0.5 3.0  0.80±0.15 50
12/4 13.2±0.8 4.0  0.85±0.15 50
15/5 16.0±0.8 5.0  0.90±0.15 50
18/6 19.5±0.8 6.0  1.00±0.20 50
24/8 26.5±1.0 8.0  1.20±0.20 25
30/10 32.0±1.5 10.0  1.20±0.20 25
39/13 41.0±1.5 13.0  1.50±0.30 25
50/16 ≥50 17  1.65±0.30 20
60/20 ≥60 20  1.75±0.30 20
70/23 ≥70 23  1.75±0.30 20
80/26 ≥80 26  1.85±0.30 20
90/30 ≥90 30  2.15±0.30 20
100/33 ≥100 33  2.35±0.30 20



Ordering instructions: Please order according to "model-specification-color", such as S2(n)-9/3-0
Color code: black (-0), brown (-1), red (-2), orange (-3), yellow (-4), green (-5), blue (-6), purple (-7) , Gray (-8), white (-9), pink (-P), brown (-T), transparent (-X)
