S3TV CATV Double-wall halogen-free heat shrinkable tube

Retail price
0.0
Market price
0.0
Number of views:
1000
Product serial number
Quantity
-
+
Stock:
0
1
Detail
Size specification
Introduction
Heat-shrinkable tube made of radiation cross-linked polyolefin, the inner layer is coated with glue, and the surface can be optionally attached with temperature-indicating paint; it has good sealing, insulation and mechanical protection properties. Suitable for CATV cable lap, sealing and insulation protection at branch joints



Features
Operating temperature: -55~110
Minimum full shrinkage temperature: 125
Single wall or double wall with glue optional
Halogen-free environmental protection
Shrink ratio: 3:1 & 4:1



Technical Data
Property Test Method Value
Tensile Strength ASTM D2671 ≥ 14 MPa
Breakdown elongation ASTM D2671 ≥ 400%
Aging(136/168hrs)
Tensile Strength
Breakdown elongation
ASTM D2671
≥ 12 MPa
≥ 350%
Water absorption(23/24hrs) ASTM D2671 ≤ 0.5%
Low temperature flexibility(-55/4hrs) ASTM D2671 No cracks
Heat shock(200/4hrs) ASTM D2671 No drips, no flow, no cracks
Dielectric strength ASTM D2671 ≥ 15 kV/mm
Volume resistivity ASTM D2671 ≥ 1×1014Ω.cm
Mold resistant ASTM D2671 Not inferior to level 1
Copper corrosion(150/16hrs) ASTM D2671 无腐蚀
Peel strength of glue to XLPE ASTM  D2671 ≥110N/25cm
Peel strength of glue to steel ASTM  D2671 ≥80 N/25cm



Dimension
Size As supplied(mm) After shrink (mm) Standard length
S3TV Diameter(Min.) Diameter(Max.) W T(reference) m
12/4 12 4 2.0 1.22
19/6 19 6 2.5 1.22
28/9 28 9 2.5 1.22
33/10 33 10 2.2  1.22
38/12 38 12 2.5  1.22
43/12 43 12 2.5  1.22
55/16 55 16 2.7 1.22
75/22 75 22 3.0 1.22



Color: black (-0), brown (-1), red (-2), orange (-3), yellow (-4), green (-5), blue (-6), purple ( -7), gray (-8), white (-9), pink (-P), brown (-T), transparent (-X), etc.
